Appendix 50
devolo Magic 1 WiFi
5.4 Bandwidth optimization
To significantly improve the transmission capacity of the
network, we recommend that you comply with the follo-
wing "connection rules":
Plug the devolo Magic directly into a wall socket.
Avoid using power strips. This may impair the trans-
mission of the PLC signals.
If there are several sockets in the wall directly next to
each other, they behave like a power strip. Individual
sockets are optimal.
3 2422 MHz
4 2427 MHz
5 2432 MHz
6 2437 MHz
7 2442 MHz
8 2447 MHz
9 2452 MHz
10 2457 MHz
11 2462 MHz
12 2467 MHz
13 2472 MHz
Channel Carrier frequency
Fig. 16: Bandwith optimization
