Dexter Laundry T-950 - Page 102

Key Description T-650 T-750 T-950 T-1450
17 Hose-Overow 9242-449-
002
9242-449-
003
9242-449-003 9242-449-
005
1
* Clamp Hose Over Flow 865 4 -117- 018 8 654 -117-018 8 654 -117-018 865 4-117- 018 2
18 Drain Valve 9379-202-001 9379-202-001 9379-202-001 9379-202-001 1
* Hose, Drain Valve to Tube 9242-464-
001
9242-456-
001
9242-459-001 9242-459-
001
1
* Clamp 865 4 -117- 014 8 654 -117-014 8 654 -117-014 865 4-117- 014 2
Hose-drainvalve,outlet 9242-457- 001 9242-457- 001 9242-457- 001 9242-457- 002 1
19 Drain Tube 9915-124-002 9915-124- 002 9915-120-004 9915-129-002 1
20 Hose-Pressure Switch 9242-175- 002 9242-175- 007 9242-175-007 9242-175-004 1
* Clamp Pressure switch Tube 86 54-117- 015 865 4 -117-015 86 54-117- 015 8 654 -117- 015 1
* Anchor-wiretie,adhesive 9004-007-
001
9004-007-
001
9004-007-001 9004-007-
001
1
1
17
12,13,14
20
1
19
18
15
16
10,11
3,4
10,11
12,13,14
15
9
7
5
6
9
5
6
8
7
9
102
Part # 8533-110-001 11/20
