Dexter Laundry T-950 - Chassis and Drain Part # by Model

Chassis and Drain Part # by Model
Key Description T-650 T-750 T-950 T-1450
1 Base Assy,Frame 9945-143-002 9945-112-002 9945-155-002 9945-133-002 1
2 Outer Tub Assy. 9930-169-001 9930 -148-002 9930 -158-001 9930-155-001 1
* Tub & Cylinder Assy. 9869-035-004 9869-025-005 9869-027-004 9869-026-001 1
3 Tub Front 9974-014-002 9974-011-001 9974-011-001 9974-012-001 1
* Gasket, Tub Front 9206-421-004 9206-421-002 9206-421-002 9206-421-003 1
4 Ring Assy, Tub Mtg-Front Clamp 9950-063-001 9950-055-001 9950-055-001 9950-061-001 1
5 Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 9545-029-009 9545-029-009 1
6 Nut 3/8”-16 8640-415 -001 8640 - 415- 001 8640-415 -001 8640 - 415- 001 1
7 Bolt, 1/2” -13 x 2” Tub feet to base 9545-017-013 9545-017-013 9545-017-013 9545-017-013 2
8 Nut, Wizloc 1/2” x 13 86 40 -417- 005 8640 - 417- 005 86 40 -417- 005 8640 - 417- 005 2
9 Washer, Flat 1/2” 8641-581-026 8641-581-026 8641-581-026 8641-581-026 2
10 Hose, Tub to Drain Valve 9242-464-001 9242-456-001 9242-459-001 9242-459-001 1
11 Clamp, Hose (Tub to Drain Valve) 865 4 -117-014 865 4-117- 014 865 4 -117- 014 865 4 -117-00 8 2
12 Valve, Drain 9379-202-001 9379-202-001 9379-202-001 9379-202-001 1
* Screw, Valve to Base 1/4ABx3/4 9545-030-002 9545-030-002 9545-030-002 9545-030-002 2
* Washer, Flat 1/4 8641-581-018 8641-581-018 8641-581-018 8641-581-018 2
13 Hose, Drain Valve to Tube 9242- 457-001 9242- 457-001 9242-457-001 9242-457-002 1
* Clamp, Hose (Drain Valve to Tube 8 654-117- 014 8 654 -117-014 865 4 -117-014 86 54-117- 0 08 2
14 Tube Assy, Drain 9915-124-002 9915-124- 002 9915-120-004 9915-129-002 1
15 Clamp, Hose (Tube to Frame Bracket) 865 4 -117- 014 8 65 4 -117-014 8 654 -117-014 865 4 -117- 014 1
* Bracket, Drain Tube 9029-162-002 1
* Screw Tube (Bracket to Base 1/4Bx3/4) 9545-030-002 9545-030-002 9545-030-002 9545-030-002 2
16 Hose, Overow Tub To Drain Tube 9242-449-002 9242-449-003 9242-449-003 9242-449-005 1
* Clamp, Hose 865 4 -117-018 865 4 -117-018 865 4 -117-018 8654-117- 018 2
17 Tube, Suds overow 9242-463-004 9242-463-004 9242-463-004 9242-463-006 1
* Clamp, Hose 865 4 -117-008 865 4-117- 0 08 8 65 4 -117-008 8 65 4 -117-008 2
18 Hose, Pressure switch 9242-175-002 9242-175-007 9242-175-007 9242-175-004 1
* Clamp, Hose 865 4 -117-015 865 4 -117-015 865 4 -117-015 8654-117- 015 1
* Anchor-wiretie,adhesive 9 004- 007-001 9004-007-001 9 004-007- 001 9004- 007-001 1
* Strap-tie,adjustableratchet 9544- 040- 001 9544-040-001 9544-040-001 9544- 040- 001 1
19 Bracket-switch,prox 9029-309-001 9029-309-001 9029-309-001 9029-309-001 1
* Washer-at 8 641- 5 81-0 4 0 8641- 5 81-040 8 641-581-040 86 41- 5 81- 040 1
* Screw-hxcap,5/8-11x3/4 9545-060-005 9545-060-005 9545-060-005 9545-060-005 1
20 Switch-prox,18mm,shld,60" 9 5 3 9-49 8-001 9539-49 8-001 9539-498-001 95 3 9- 498-001 1
21 Sensorassembly-thermistor,10k 9501-005-0 02 9501- 0 05-0 02 9501- 0 05-0 02 9501-0 05 -002 1
* Sealer-pipe 8538-132- 000 8538-132- 000 8538-132- 000 8538-132- 000 1
116
Part # 8533-110-001 11/20
