Dexter Laundry T-950 Parts & Service Manual

Cylinder, Seals & Bearings Part # by Model
Key Description T-650 T-750 T-950 T-1450
1 Housing, Bearing- Assembly (items #2-#6) 9803-187-001 9803-187-001 9803-187-001 9803-209-001 1
2 Housing, Bearing 9241-181-004 9241-181-004 9241-181-004 9241-195-003 1
3 Bearing, Front (LARGE) 9036-159-005 9036-159-005 9036-159-
005
9036-162- 002 1
4 Bearing, Rear (SMALL) 9036-159-006 9036-159-006 9036-159-
006
9036-162- 001 1
5 Spacer, Bearing 9538 -170- 001 9538-170-001 9538-170-001 9538-185 -001 1
6 Ring, Bearing Retainer 9487-238-004 9487-238-004 9487-238-004 9487-238-004 1
7 Tub Assembly 9930-169-001 9930-148- 002 9930-158- 001 9930 -155-001 1
8 Seal, Primary V85A 9532-140-007 9532-140 -007 9532-140-007 1
8 Seal, Primary V95A 9532-140-012 1
9 Seal, Secondary V140A 9532-140-008 9532-140-008 9532-140-008 9532-140-008 1
10 Ring, Seal Mounting 9950-052-001 9950-052-001 9950-052-
001
9950-062-001 1
11 Tub Back Ring Seal 9487-266-001 9487-266-001 9487-266-001 9487-276-001 1
Mating Ring Seal 9487-261-004 9487-261-004 9487-261-004 9487-261-005 1
12 Bolt, Tub End of Bearing Housing (7/16-14x1), Bolt
from inside Tub
9545-059-004 9545-059-004 9545-059-
004
9545-059-004 6
13 Washer, Flat 8641-581-034 8641-581-034 8641-581-034 8641-581-034 6
14 Screw-Hex Cap, 3/4”-10 x 3” (Bearing Housing to
Frame)
9545-057-002 9545-057-002 9545- 057-
002
6
14 Screw-Hex Cap, 7/8”-10 x 3” (Bearing Housing to
Frame)
9545-066-001 6
15 Washers Spherical 3/4 (Male half) (Bearing Housing
to Frame)
8641-588-001 8641-588-001 8641-588-001 6
15 Washers Spherical 7/8 (Male half) (Bearing Housing
to Frame)
8641-588-003 6
16 Washers Spherical 3/4 (Female half) (Bearing Hous-
ing to Frame)
8641-588-002 8641-588-002 8641-588-
002
6
16 Washers Spherical 7/8 (Female half) (Bearing Hous-
ing to Frame)
8641-588-004 6
17 Nut 3/4”-10 (Bearing Housing to Frame) 8640-418 -003 8640- 418- 003 86 40 -418 -
003
6
17 Nut 7/8”-9 (Bearing Housing to Frame 8640- 437-001 6
18 Pulley, Driven 9453-173-002 9453-173-002 9453-176-006 9453-176-006 1
* Tolerance Ring 9487-234-004 9487-234-004 1
* Screw, 5/8”-11 x 2” 9545-060-004 9545-060-004 1
* Washer-Flat, 5/8” 8641-581-032 8641-581-032 1
* Washer-Flat, 5/8” 8641-582-018 8641-582-018 1
19 Bolt, 3/8”-16 x 2” 9545-029-
011
9545-029-011 3
20 Washer, 3/8” 8641-582-003 8641-582-003 3
21 Bushing Taperlock (Driven & Large 9053-078-
002
9053-078-002 1
22 Washer-Flat .675x2-1/2x1/4 8641-581-043 1
23 Lockwasher-Exttooth, 5/8 8641-582-018 1
24 Bolt, 5/8-11x1 1/2 9545-060-
001
1
22 Washer-Flat, .781x2-1/2x1/4 8641-581-044 1
23 Lockwasher-Exttooth, 3/4 8641-582-020 1
24 Bolt, 3/4-10 -1 1/2 9545-057-004 1
25 Tub & Cylinder Assy 9869-035-004 9869-025-005 9869-027-
004
9869-026-001 1
105
Part # 8533-110-001 11/20
