Dexter Laundry T-950 Parts & Service Manual

Key Description T-650 T-750 T-950 T-1450
27 Cylinder Assy 9848-145-001 9848-136-002 9848-136- 001 9848-141-0 01
* Tub Front 9974-014-002 9974-011-001 9974-011-001 9974-012-001 1
* Gasket, Tub Front 9206-421-004 9206-421-002 9206-421-002 9206-421-003 1
* Ring Assy, Tub Mtg-Front Clamp 9950-063-001 9950-055-001 9950-055-001 9950-061-001 1
* Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 9545-029-009 9545-029-009 1
* Nut 3/8”-16 8640-415 - 001 8640- 415-001 8640 - 415- 001 8640 - 415- 001 1
11
7
9
8
10
25
19,20
18
21,22,23,24
8
9
11
11 G
8
9
10
5
6
3
12,13
42
1
27
14,15,16,17
106
Part # 8533-110-001 11/20
