Dexter Laundry T-950 - Cabinet and Front Panel Group Part # by Model

Cabinet and Front Panel Group Part # by Model
Large Door
Key Description T-650 T-750 T-950 T-1450
1 Panel, Side- stainless 9989-644-001 9989-645-001 2
1 Panel, Side- stainless 9989-644-002 9989-645-002 9454-839-001 9454-836-001 4
* Bolt-1/4-20x1/2 (side panel Front to Rear) 9545-018-013 9545-018-013 9545-018-013 8
Nut 1/4-20UNC (side panel) 8640- 414- 006 8640-414-006 8640- 414- 006 8
Strap Assy (Side to base) 9966-013-001 2
Strap Assy (Side to base) 9966-012-001 9966-012-001 9966-012-001 4
* Shim (side panel) 9552-039-001 9552-041-001 9552-039-001 9552-044-001 2
* Nut, Hex 1/4-20 UNC 8640 - 414 -006 8640 - 414- 006 8640-414-006 8640 - 414- 006 8
2 Bracket, Side Panel under front panel 9046-094-001 9046-085-001 9046-085-001 9046-086-001 1
* Screw #10Bx1/2 side panel brkt 9545-008-026 9545-008-026 9545-008-026 9545-008-026 1
* Nut #10-32 UNF side panel brkt 8640-413-002 8640 - 414- 00 6 8640-414-006 1
3 Panel Assy, Front 9989-615-003 9989-616-003 9989-617-003 9989-619-003 1
4 Bumper Loading Door 9051-055-001 9051-055-001 9051-055-001 9051-055-001 1
* Nut, 1/4 x 20 for bumper 8640- 414- 003 86 40-414-003 8640- 414- 003 86 40 -414 -003 1
* Screw, #10B x 1/2 9545-008-023 9545-008-023 9545-008-023 9545-008-023 2
* Nut, Spring- To Control Panel 10/32 8640-399-008 8640-399-008 8640-399-008 8640-399-008 2
5 Screw, Flat Head- Front to Sides 9545-008-014 9545-008-014 2
5 Screw, Flat Head- Front to Sides 9545-008-014 9545-008-014 4
6 Washer, Finish 8641- 585- 001 8641-585 -001 2
6 Washer, Finish 8641-585-0 01 8641- 585-001 4
* Nut, Spring-To Front Panel 8640-399-008 8640-399-008 8640-399-008 8640-399-008 2
* Label, Door Opening (Black) 8502-757- 001 8502-757-001 8502-757-001 8502-757-001 1
8 Panel, Control (Mounts Nameplate) 9989-599-001 9989-600-001 9989-600-001 9989-601-001 1
* Screw, Control Panel to Sides 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
9 Nameplate Decal, Control Black 9412-243-001 9412-244-001 9412-245-001 9412-246-001 1
10 Panel Top 9989-563-007 9454-743-001 9454-736-001 1
11A Panel Top Front 9454-850-001 1
11B Panel Top Rear 9454-851-001 1
12 Lock, Top (w/Key) 8650-012-003 1
12 Lock, Top (w/Key) 8650-012-003 8650-012-003 8650-012-003 2
* Lock Spacer 9538-189-001 9538-189-001 9538-189-001 9538-189-001 1
13 Door, Lower Service, Includes Handle 9960-286-002 9960-286-004 9960-286-004 9960-286-005 1
14 Handle (bumper guard) 9244-086-002 9244-086-003 9244-086-003 9244-086-004 1
* Rivet Blind 3/16” Alum 9491-009-003 9491-009-003 9491-009-003 9491-009-003 4
* Screw 9545-008-023 9545-008-023 9545-008-023 1
96
Part # 8533-110-001 11/20
