Key Description T-650 T-750 T-950 T-1450
1 Panel Control Assembly(panel only) 9989-599-001 9989-600-001 9989-600-001 9989-601-001 1
* Screw-Hxwshrhdundct #10Bx 1/2”(Control Panel
To side Panel)
9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
* Plate -Latch, Top 9452-625-001 9452-625-001 9452-625-001 9452-625-001 AR
* Nut Hexkeps #8-32 8640 - 412- 005 86 40 -412- 005 8640 - 412- 005 8640 - 412- 005 AR
* Post-locator,top 9467-024- 001 2
* Nut-hexkeps,#6-32 8640 - 411-003 2
* Locator Panel 9355-001-001 9355-001-001 9355-001-001 9355-001-001 AR
* Screw FillHDCR 10Bx1/2” Guide 9545-008-023 9545-008-023 9545-008-023 9545-008-023 AR
* Shield, PCB 9550-184-001 9550-184-001 9550-184-001 9550-184-001 1
* Nut, #8-32 8640-412-005 8640-412-005 8640 - 412- 005 8640- 412- 005 3
2 Button-control,2.0,opl 9035- 063-001 9035-063-001 9035-063-001 9035-063 - 001 1
3 Window-display,lcd(w/gasket) 9 63 5 -021-002 9635-021-002 9 6 3 5- 021-0 02 9635 -021-002 1
4 Contrlassy-display,2.0,opl,wsh 9857- 230 -0 03 9857- 230 -003 9857- 230 -003 9857- 230 -003 1
5 Nut-hexkeps,#6-32 86 40- 411- 0 03 8640 - 411-003 8640 - 4 11-003 8640 - 4 11-003 4
6 Cableassy-usb,snapin 9806-024-001 9806-024-001 9806-024-001 9806-024-001 1
* Wiringharness-doorlock 9627-9 36-00 3 9627-936 -001 96 27-936-00 1 9627-9 36 -004 1
* Harness, P5/Pressure Switch 9627-926-001 9627-926 -001 9627-926-001 9627-926 -001 1
* Kit-Emergency Stop, O-Series (includes #X, #Y) 9732-223-004 9732-223-004 9732-223-004 9732-223-004 1
7 Button-emergencystop,w/latch 9035-061-002 9035- 061- 002 9035-061-002 9035-061-002 1
8 Spacer-pcb,#8x1/8 9538 -157- 005 9538-157-005 9538-157-005 9538 -157- 0 05 2
9 Plate-mounting,stopbutton 9452-725-001 9452-725 - 001 9452-725-001 9452-725 - 001 1
10 Nut-hexkeps,#8-32 8640- 41 2-005 8640-412-005 8640- 41 2- 005 8640-412 - 005 2
11 Switch-contactblock,dpst,nc 9539-499-001 9539-499-001 9539-499-001 9539- 499-001 1
* Nameplate,Control Panel (one piece) Black 9412-243-001 9412-244-001 9412-245-001 9412-246-001 1
12 Motor Ass’y, Door Locking (see Door Lock Group
for parts breakdown)
9892-015-003 9892-015-003 9892-015-003 9892-015-003 1
13 Thermoactuator - 24VAC 9586-001-003 9586-001-003 9586-001-003 9586-001-003 2
14 Hex Nuts (mounting Door Lockassy. to control
panel)
8640-412-005 8640-412-005 8640 - 412- 005 8640- 412- 005 4
15 Nut-Spring 8640-399-008 8640-399-008 8640-399-008 8640-399-008 2
16 Screw, #10B x 1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 2
* Anchor-wiretie,adhesive 9004-007-001 9004- 007-001 9004-007-001 9004-007-001 2
* Strap-tie,adjustableratchet 9544-040- 001 9544-040-001 9544-040-001 9544-040 - 001 2
17 Doorlockassembly-complete 9885-024-001 9885-024-001 9885-024-001 9885-024-001 1
Shim-doorlock,thin 9552-037-001 9552-037-001 9552-037-001 9552-037-001 3
Screw-hxhdcap,1/4-20x3/4 954 5-018-014 954 5-018-014 9545-018-014 9545-018-014 3
Lockwasher-exttooth,1/4 86 41 - 582- 007 8641- 582- 007 8641-582-007 8641-582 - 00 7 3
18 Rod-pull,doorlock 9497-225- 017 9497-225 -013 9497-225-015 9497-225-016 1
18
17
120
Part # 8533-110-001 11/20
