Key
Component T-650 T-950
QTY
1 LABEL-WARNING,HIGHVOLTAGE 8502-614-004 8502-614-004 2
2 LABEL-QUALITY 8511-001-002 8511-001-002 2
3 LABEL-FUSING&INSTALLATION 8502-619-006 1
4 NUT-HEXKEPS,#8-32 8640 - 412- 005 8640-412-005 13
5 NUT-HEXKEPS,#10-32UNF,2B 8640-413-002 8640- 413- 002 12
6 LOCKWASHER-EXTTOOTH,#10 8641-582-006 8641-582- 006 12
7 BUSHING-INSULATED,1” 9053-067-004 9053-067-004 4
8 STUD-SELFCLINCHING,#10-32X1/2 9531-042-002 9531-042-002 4
9 SCREW-HXWSHRHDUNDCT,#10BX1/2 9545-008-026 77
10 SCREW-HXWSRHDSL,10-32TTX1/2GRN 9545-008-027 8
11 SCREW-PNHDCR,6ABX3/4 9545-031-010 9545-031-010 4
12 TERMINALBLOCKASSEMBLY-POWER 9897-033-002 9897-033-002 2
13 LABEL-FUSING&INSTALLATION 8502-619-006 1
14 NUT-ELASTICSTOP,#6-32 864 0 - 411-002 86 40- 411- 002 4
15 TERMINAL-LUG,SOLDERLESS 8652-134-002 8652-134-002 1
16 ANGLE-SUPPORT,DRIVE(HEATED) 9003-341-001 9003-341-001 1
17 BRACKET-SHIELDMOUNTING 9029-095-001 9029-095-001 1
18 BRACKET-SHIELD,RH 9029-193-001 1
19 COVER-HEATER TERMINALS 9 074-331- 001 9 074-331- 001 1
20 COVER-DRIVE (W/FAN) 9074-362- 001 9074-362-001 1
21 CHANNEL-REAR,T-650HTD 9081-177-001 1
22 FAN-COOLING,120VAC 9189-012-001 9189-012-001 1
23 GUARD-COOLINGFAN,80X80MM 9208-063-001 9208-063-001 1
24 HOUSING-SUMP,DRAIN,HTD 9241-201-001 1
* HOUSINGASSEMBLY-SUMP,DRAIN 9803-191-001 1
25 HOSE-DRAIN 9242-459-001 1
26 PLATE-MTG,DRIVE(HTD) 9452-842-001 9452-842-001 1
27 PLATE-BASE,DRIVEMTG(HTD) 9452-843-001 9452-843-001 1
28 WIRINGLABEL-DIAGRAM/INFORM 9507-014-001 9507-005-001 1
29 WIRINGLABEL-SCHEMATIC 9508-014-001 9508-005-001 1
30 STRAP-FAN,LANYARD 9544-067-001 9544-067-001 1
31 SCREW-PNHDCR,#8-32X3/4 9545-010-001 9545-010-001 3
32 SCREW-RDHDSLTDMACH,#10-32 9545-012-004 9545-012-004 4
33 SCREW-HXWSHDSL,6BX3/8 9545-031-003 9545-031-003 2
34 SCREW-HXWSHRHD,#6-32X11/2 9545-044-009 9545-044-009 1
35 SCREW-HXWSHRHD,#6-32X5/8 9545-044-012 9545-044-012 3
37 VALVEASSY-DRAIN,T-650HTD,120V 9819-026-003 1
38 CNTRL-TRGH,T650OPL,OHTD-13 9857-243-003 1
39 TUB&CYLASSY-CMP,T-650,OPL-HTD 9869-035-003 1
40 HEAT ER ASS EM B LY 9870-087-001 9870-087-001 6
41 TERMBLKASY-INPUTPWR-13OPLHTD 9897-041-013 1
* TERMBLKASY-INPUTPWR-13OPLHTD 9897-042-014 1
42 DRIVEASSY-W/BRKT,T-650OOPL,HTD 9909-044-004 1
* DRIVEASSY-W/BRKT,T-950OOPL,HTD 9909-047-004 1
43 TUBASY-WELD,T-650,30CYCOPL-HTD 9930-170-001 1
* TUBASSY-WELD,T-900,ELEC/STMHTD 9930-158-002 1
44 CHANNELASSY-REAR,T-650HTD 9947-033-001 1
* CHANNELASSY-REAR,T-900/1200HTD 9947-031-001 1
WN0650XB-13E0 Parts
164
Part # 8533-110-001 11/20
