Dexter Laundry T-950 Parts & Service Manual

Top Mount Detergent Dispenser
Key Description T-650 T-750 T-950 T-1450 QTY
1 Dispenser Soap 9122-005-
004
9122-005-
004
9122-005-004 1
2 Gasket Dispenser 9206-416-
001
9206-416-
001
9206-416-001 1
* Hose, Dispenser to tub 9242-450-
003
9242-450-
001
9242-450-001 1
* Clamp 865 4 -117- 008 8 65 4 -117-008 865 4 -117-00 8 2
* Nut, Spring ss 8640-399-
007
8640-399-
007
8640-399-007 4
* Flow resistors 9475-002-
002
9475-002-
002
9475-002-002 2
* Flow resistors Optional (Smaller) 9475-002-
003
9475-002-
003
9475-002-003 2
3 Door, Dispenser 9108-095-
005
9108-095-
005
9108-095-005 1
4 Pin, Plain 9451-191-001 9451-191-001 9451-191-001 2
* Post, Door Mounting 9467-025 -
001
9467-025 -
001
9467-025-001 2
6 Screw- 8B x 1/2 9545-045-
002
9545-045-
002
9545-045-
002
4
Screw, SS Dispenser, 10B x 1 9545-008-
012
9545-008-
012
9545-008-012 4
* Washer Flat 5/16 8641-581-008 8641-581-008 8641-581-008 8641-581-008 1
8 Plastic Sleeve, Locator 9355-001-
001
9355-001-
001
9355-001-001 9355-001-001 2
* Catch, Top Panel 9086- 017-
001
2
Lock, Top (w/Key) 8650-012-
003
1
* Lock, Top (w/Key) 8650-012-
003
8650-012-003 8650-012-003 2
Channel-support,dispenser 9081-108-001 9081-108-002 9081-108-001 1
Screw-hxwshrhdundct,#10bx1/2 9545-008-
026
9545-008-
026
9545-008-
026
1
Screw-hxwshdsl,10bx1/4 9545-008-
001
9545-008-
001
9545-008-
001
2
99
Part # 8533-110-001 11/20
