Page #112 background imageLoading...
Page #112 background image
Key Description T900 T1200 QTY
1 Channel Assembly, Rear 9497-028-001 9497-028-001 1
* Screw, #10B x 1/2 9545-008-026 9545-008-026 4
* Clip, Spring 8640-399-004 8640-399-004 4
2 Mounting Plate Water Valves 9452-814-001 9452-814-001 1
3 Nut-Elastic stop, #10-32 8640-413-002 8640-413-002 2
4 Valve, Water Inlet (dual outlet) (see Water Inlet Valve
Breakdown for individual parts)
9379-183-010 9379-183-010 2
5 Screw, Valve Mtg 9545-008-026 9545-008-026 4
6 Plate-Cover, Valves 9452-815-001 1
7 Screw, #10B x 1/2 9545-008-026 1
8 Valve, Water Inlet (Single outlet) (see Water Inlet Valve
Breakdown for individual parts)
9379-194 -001 2
* Screw, M4x0 7 x 8mm 9545-064-001 4
* Wire-Assy, Jumper, Yellow 8220-123-001 8220-119-002 1
9 Shield over Water Valves Plastic 9550-195-001 9550-195-001 1
10 Push Clip 9083-121- 001 9083-121-001 3
11 Vacuum Breaker 9610-001-001 9610-001-001 1
12 Fill Cap, (Red) 0935-135-002 0935-135-002 3
* Bracket, Vacuum Breaker 9029-077-001 9029-077-001 1
13 Screw, #10B x 1/2 9545-008-026 9545-008-026 4
* Clamp, Hose to Vacume Braker 8654-117-014 8654-117-014 1
* Hose, Vacuum Breaker to Tub 9242-458-003 9242-458-003 1
* Clamp, Tub End 8654 -117-009 8654-117-009 1
* Hose, overow Suds 9242-463-004 9242-463-004 4
* Clamp, Hose-Spring (overow to tub back) 8654-117-018 8654 -117-018 2
14 Plate Assembly, Drive Mounting 9982-383-001 9982-383-001 1
15 Nut-#10-32UNF, 2B 8640-413-002 8640-413-002 4
16 VFD Delta “E drive 208-240 volt 9375-028-014 9375-028-012 1
* Wire assy Brown, 3” 8220-057-035 8220-057-035 1
* Wire assy Red, 3” 8220-057-036 8220-057-036 1
* Key Pad-Display Delta “E” Drive 9150-044-001 9150-044-001 1
* Cable-Data, Communication 9806-015-001 9806-015-001 1
17 Bushing, 7/8 9053-067-002 9053-067-002 1
18 Plug, 7/8 9545-041-006 9545-041-006 1
19 Bracket, Terminal-Mounting 9029-265-001 9029-265-001 1
20 Screw, #10B x 1/2 9545-008-026 9545-008-026 4
21 Label-Warning 8502-639-001 8502-639-001 1
22 Strip-Terminal Marker 9558-025-001 9558-025-001 1
23 Terminal Block 9897-033-002 9897-033-002 1
24 Screw-Phillips, 6ABx3/4 9545-031-010 9545-031-010 2
25 Harness-Power, Terminal Block 9627-747-003 9627-747-002 1
26 Bushing, 1 9053-067-004 9053-067-004 1
27 Terminal Lug, Solderless 8652-134 -001 8652-134-001 1
28 Lock-Washer, 1/2 8641-582-006 8641-582-006 1
29 Screw, #10-32 TTX 1/2 GRN 9545-008-027 9545-008-027 1
Water Inlet & Rear Channel
112
Part # 8533-081-001 1/18
