PROGRAMMING INSTRUCTIONS:
The washer control can be programmed to prompt the user for alternate vend prices, change washer cycle
times, temperatures and many other options. This can be accomplished in two ways:
1. Manual programming utilizing the “Start”, “Hot”, “Warm” and “Cold” buttons
2. USB download
For instructions on using the USB download feature, please contact your local Dexter distributor.
MANUAL PROGRAMMING:
The washer must be in idle mode for the manual programming menus to be accessed. Idle mode is when
the washer is not actively running a wash cycle and the vend price is displayed on the screen.
To enter the manual programming mode, the top of the washer must be unlocked and lifted slightly (it
should not be necessary to remove the screws for the soap box). The programming button is then pressed
for 1 second. The control should display “PROGRAMMING”.
See Figure 1 for the location of the programming button in relation to the USB port (The USB port is ex-
posed when the washer top is lifted).
Figure 1
When manual programming mode is entered, the “Start”, “Hot”, “Warm” and “Cold” buttons perform alter-
nate functions.
Button Name Alternate Function in Programming Mode
Start Becomes the action to accept the displayed option or the “Enter” key
Hot
Becomes the action to move UP through displayed options (Press & hold
for accelerated scrolling)
Warm Becomes the action to move DOWN through displayed options (Press &
hold for accelerated scrolling)
Cold Becomes the action to move back a step (1 press) or EXIT from
programming mode (press for 3 seconds)
36
Part # 8533-081-001 1/18
