Dexter Laundry WC0900-XA12ECX - Cabinet and Front Panel Group Part # by Model

Cabinet and Front Panel Group Part # by Model
Key Description T900 T1200 QTY
1 Panel, Side (Left or Right) - stainless 2
1 Panel, Side (Left or Right) - stainless 9454-839-001 9454-814-001 4
* Strap Assembly (side panel) 9966-012-001 9966-012-002 2
* Shim (side panel) 9552-039-001 9552-042-001 2
* Nut, Hex 1/4-20 UNC (for strap assembly 6
* Nut, Hex 1/4-20 UNC 8640-414-006 8640-414-006 8
2 Bracket, Side Panel under front panel 9046-085-001 9046-085-001 1
3 Screw #10Bx1/2 side panel brkt 1
4 Nut 1/4-20 UNC side panel brkt 1
• Nut, Hex 8640-414-006 8640-414-006 2
* Screw 9545-008-026 9545-008-026 2
5 Panel Assy, Front 9454-840-001 9454-811-001 1
* Band, Edge Protector 9578-092-002 9578-092-002 1
6 Bumper Loading Door 9051-055-001 9051-055-001 1
* Nut, 1/4 x 20 for bumper 8640-414-006 8640-414-006 1
* Screw, Hex- To Control Panel 9545-008-026 9545-008-026 2
* Nut, Spring- To Control Panel 10/32 8640-399-005 8640-399-005 2
7 Screw, Flat Head- Front to Sides 9545-008-014 2
7 Screw, Flat Head- Front to Sides 9545-008-014 4
8 Washer, Finish 8641-585-001 2
8 Washer, Finish 8641-585-001 4
* Nut, Spring-To Front Panel 8640-399-008 8640-399-008 2
9 Label-Door Opening (Blue 8502-757-002 8502-757-002 1
9 Label-Door Opening (Black) 8502-757-001 8502-757-001 1
10 Label-Risk of Injury (Blue) 8502-759-002 8502-759-002 1
10 Label-Risk of Injury (Black) 8502-759- 001 8502-759-001 1
11 Panel, Control (Mounts Nameplate) 9989-560-001 9989-560-001 1
* Screw, Control Panel to Sides 9545-008-026 9545-008-026 4
12 Nameplate Decal, Control Blue 9412-206-002 9412-214-002 1
12 Nameplate Decal, Control Black 9412-206-001 9412-214-001
13 Panel Top 9454-736-0 02 1
14A Panel Top Front 9454-761-001 1
14B Panel Top Rear 9454-762- 001 1
15 Lock, Top (w/Key) 8650-012-003 8650-012-003 2
* Key, Top- # 6324 6292-006-007 6292-006-007 1
* Cam, Lock-Top 9095-049-001 9095-049-001 1
* Nut, 9/32 - 28 Hex 8640-426-001 8640-426-001 1
* Washer Flat 5/16 8641-581-008 8641-581-008 1
16 Door, Lower Service, Includes Handle 9960-286-004 9960-286-004 1
100
Part # 8533-081-001 1/18
