Fault Description Customer Action
SLOW
DRAIN
ERROR
Drain Error Condition This error is when an empty water level is not
reach within 7 minutes.
Delay Immediate
Action The washer cycle will continue. Do not spin
the tumbler with out reaching an empty water
level. If empty water level is not reached,
agitate during the normal spin time.
Solution Check VFD fault light before turning o power.
Check to ensure the drain valve is operating
properly (slow drain has potential to cause this
code). Check to ensure the pressure switch
tube is clear of any blockage, and the pressure
switch is operating properly. Check the
pressure switch harness.
SPIN
STOP
ERROR
Stop Error Condition This error is when the washer does not stop
spinning within 150 seconds after receiving the
command.
Delay Immediate
Action Keep the door locked until the machine has
stopped moving and then unlock the door.
Solution Check VFD fault light before turning o power.
Inspect the braking resistors and measure
the resistance. Check connecting wiring from
braking resistor to the drive mounted in the top
of the washer. Reset the drive and try again.
Possibly incorrectly programmed drive.
DRIVE
ERROR
1
Washer size/ VFD
size mismatch
Condition This error is when the drive size does not
match the washer size.
Delay Immediate. (after the size jumper conguration
is read). Washer size/type inputs are read
only at power up, before starting a cycle, once
every 24 hours and in factory test mode
Action Stop the machine and clear the cycle. Keep
the door locked until the machine has stopped
moving and then unlock the door
Solution Check VFD fault light before turning o power.
If the controller was installed in a dierent
size machine before being installed in this
machine, a problem can occur. If someone has
been doing repairs on the washer, check for
the correct size drive. It can also be caused by
pressure switch harness. Check to ensure the
correct harness in installed. The control can be
reset by holding program button on controller
during startup (soft reset). Check orange wire
at Molex connector on controller coming from
pressure switch or replace pressure switch
harness.
61
Part # 8533-081-001 1/18
