Dexter Laundry WCAD Series - Section 6: Service Electrical Components; Control Trough Components

Optical Coin Acceptor
Starting after serial# 515483
Key- Description T-750 T-900 T-950 T-1200 T-1450
1 Optical Coin Acceptor 9021-092-002 9021-092-002 9021-092-002 9021-092-002 9021-092-002 1
2 Replacement Optical Sensor 9801-099-001 9801-099-001 9801-099-001 9801-099-001 9801-099-001 1
* Screw, Highth Bar, 3mm 9545-039-002 9545-039-002 9545-039-002 9545-039-002 9545-039-002 2
Imonex Optical Coin Acceptor
Starting after serial# 515483
Key- Description T-750 T-900 T-950 T-1200 T-1450
1 Optical Coin Acceptor 9021-034-001 1
118 119
Part # 8533-073-001 3/22 Part # 8533-073-001 3/22
