Chapter 2 Hardware Installation
Chapter 2
System Memory
Features
• 2GB/4GB DDR3L ECC memory down (-E45/-E27/-E26/-E25/-E15)
2GB/4GB DDR3L memory down (-J00/-N30/-N07)
• Supports DDR3L 1333MHz (-E45/-E27/-J00/-N30/-N07)
Supports DDR3L 1066MHz (-E26/-E25/-E15)
• Supports single channel memory interface
Important:
Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in
boards, and other components. Perform installation procedures at an ESD workstation
only. If such a station is not available, you can provide some ESD protection by wear-
ing an antistatic wrist strap and attaching it to a metal part of the system chassis. If
a wrist strap is unavailable, establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.
Important:
When the Standby Power LED lights red, it indicates that there is power on the
system board. Power-off the PC then unplug the power cord prior to installing any de-
vices. Failure to do so will cause severe damage to the motherboard and components.
Standby
Power LED
3
DDR3L
DDR3L
