Chapter 3
www.df .com
37
Chapter 3 BIOS Setup
NIC Configuration
This field is used to configure the network device.
Specifi es the port speed
used for the selected
boot protocol.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Link Speed
W
ake on LAN
Advanced
[Auto Negotiated]
[Disabled]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Reset
ESC: Exit
Link Speed
Specify the port speed which is used f or the selected boot protocol.
Wake on LAN
Enable the server to be powered on using an in-band magic packet.
Intel(R) I210 Gigabit Network Connection - 00:01:29:51...
This section is used to configure the par ameters of Gigabit Ethernet device.
Confi gure Boot Protocol,
Wake on LAN, Link
Speed, and VLAN.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
PORT CONFIGURATION MENU

NIC Confi guration
Blink LEDs
PORT CONFIGURATION INFORMATION
UEFI Driver:
Adapter PBA:
Chip Type
PCI Device ID
Bus: Device: Function:
Link Status
MAC Address
Virtual MAC Address
Advanced
0
Intel(R) PRO/1000 5.5.19
001300-000
Intel i210
1533
02:00:00
[Disconnected]
00:01:29:51:00:00
00:01:29:51:00:00
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F4: Save & Reset
ESC: Exit
Blink LEDs
Identify the physical network port by blinking the associated LED .
Link Status
This field indicates the link status of the network device.
Virtual MAC Address
This field indicates progr ammatically assignable MAC address f or the network port.
