Chapter 3 BIOS Setup
Chapter 3
Enable or Disable the
Root Port
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
PEG Port Confi guration
PEG 0:1:0
Enable Root Port
Max Link Speed
Chipset
Select Screen
Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Not Present
[Enabled]
[Auto]
Enable Root Port
Enable or disable the root port.
Max Link Speed
Configure PEG 0:1:0 Max Speed: Auto, Gen1, Gen2 or Gen3.
PCI Express Confi guration
settings
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
PCH-IO Confi guration
PCI Express Confi guration
SATA And RST Confi guration
HD Audio Confi guration
LAN1(I219)
Wake on LAN Enable
State After G3
Chipset
Select Screen
Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
[Enabled]
[Enabled]
[S0 State]
PCI Express Configuration
This section configures PCI Express settings. Refer next page for more information.
SATA And RST Configuration
This section configures SATA Device Options settings. Refer page 49 for more informa-
tion.
HD Audio Configuration
This section configures HD Audio Subsystem settings. Refer page 49 for more informa-
tion.
LAN1(I219)
Enable or disable onboard NIC.
Wake on LAN Enable
Enable or disable integrated LAN to wake the system.
State After G3
This field is to specify what state the system shoule be in when power is re-applied
after a power failure (G3, the mechanical-off, state).
S0 State The system is in working state.
S5 State The system is in soft-off state, except for trickle current to devices such as
the power button.
PCH-IO Configuration
This section configures the PCH parameters.
PEG Port Configuration
This section configures the PEG port.
To Next Page
