DFI CS330 User Manual

www.dfi .com
48
Chapter 3 BIOS Setup
Chapter 3
PCI Express Root Port
Settings.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
PCI Express Confi guration

PCIE2

I211

Mini PCIE

M.2
Chipset
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
PCIE2
Hot Plug
PCIe Speed

[Enabled]
[Disabled]
[Auto]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Contol the PCI Express
Root Port.
PCIE2/I211/Mini PCIE (for CS630-Q370 only)/M.2 (for CS630-Q370 only)
This field is used to enable or disable the PCI express root port.
Hot Plug
Enable or disable the hot plug function of the PCI Express root port.
PCIe Speed
Select the speed of the PCI Express root port: Auto, Gen1, Gen 2 or Gen3.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
I211

[Enabled]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Contol the PCI Express
Root Port.
Chipset
Chipset
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
M.2
Hot Plug
PCIe Speed

[Enabled]
[Disabled]
[Auto]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Contol the PCI Express
Root Port.
Chipset
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
Mini PCIE
Hot Plug
PCIe Speed

[Enabled]
[Disabled]
[Auto]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Contol the PCI Express
Root Port.
Chipset
