5. MAINTENANCE, ADJUSTMENTS AND CALIBRATION
Page 83 © 1998 DH Instruments, Inc.
5.1.5.1.2 Pneumatic Schematic
See Section 5.1.5.2 Figure .2.
PART NUMBER DESCRIPTION # REQUIRED
100314 Cross connector 2
100318 Adaptor 2
100326 Tee connector 1
100355 2 micron filter 2
100817 Volume cylinder 1
100851 50 psia transducer 1
100856 1000 psia transducer 1
100898 Flow controller 1
100899 Flow controller 1
100931 Adaptor 4
101406 Adaptor 2
101487 Tee connector 1
101490 Elbow connector 1
101527 Bulkhead connector 4
101981 Union connector 3
101983 Reducer adaptor 1
101985 Union 1
101987 Adaptor 3
102174 Bulkhead connector 1
102189 Adaptor 3
102192 Seal 1
102194 Solenoid valve 1
102194 Solenoid valve 3
102196 Tee connector 1
102273 Union connector 3
102280 Pressure plug 1
102394 O-ring 18
102488 Solenoid valve 2
102489 Solenoid valve 1
102490 Pressure relief valve 1
102491 Adaptor 2
102525 Reducer connector 1
102526 Reducer connector 2
122511 Union connector 18
122529 Pressure manifold 2
