PPC2 AF OPERATION AND MAINTENANCE MANUAL
© 1998 DH Instruments, Inc. Page 84
5.1.5.1.3 Pneumatic Assembly
See Section 5.1.5.2 Figures .3, .5 and .6.
PART NUMBER DESCRIPTION # REQUIRED
100969-Z Lock washer 10
100971-Z Lock washer 4
100972-Z Hex nut 4
101000-Z Screw, M3 X 6 4
101005-Z Screw, M3 X 10 4
102398-Z Screw, 6-32 X 1/4 6
102566-Z Screw, 6-32 X 1/4 4
401276 (W2) Valve cable 1
100314 Cross connector 3
100318 Adaptor 2
100326 Tee connector 1
100355 2 micron filter 2
100817 Volume cylinder 1
100851 50 psia transducer 1
100856 1000 psia transducer 1
100898 Flow controller 1
100899 Flow controller 1
100931 Adaptor 4
101032 Screw, 1/4-20 X 1 1/4 4
101033 Screw, 1/4-20 X 1 8
101406 Adaptor 2
101487 Tee connector 1
101490 Elbow connector 1
101527 Bulkhead connector 4
102174 Bulkhead connector 1
102189 Adaptor 3
102192 Seal 1
102194 Solenoid valve 4
102196 Tee connector 1
102280 Pressure plug 1
102394 Viton O-ring 18
102488 Solenoid valve 2
102489 Solenoid valve 2
102490 Pressure relief valve 1
122508 Valve housing 1
122509 Valve bracket 1
122511 Union connection 18
122529 Pressure manifold 2
