5. MAINTENANCE, ADJUSTMENTS AND CALIBRATION
Page 85 © 1998 DH Instruments, Inc.
5.1.5.1.4 Rear Panel Assembly
See Section 5.1.5.2 Figures .4, .11 and .12.
PART NUMBER DESCRIPTION # REQUIRED
100632-Z Crimp terminal 31
100970-Z Nut, M3 4
100482 RS-232 socket 4
100589 Fuse, slo-blo 1A/250V 2
100985 Screw, M3 X 20 4
101469 Rubber grommet 1
102169 Fan power connector 1
102337 Cooling fan 1
102338 Fan guard 1
102417 Power entry module 1
102476 Gasket 2
122518 Rear panel 1
401268 Rear micro board 1
100997-Z Screw, M3 X 10 5
5.1.5.1.5 Electronic Chassis (Power Supplies)
See Section 5.1.5.2 Figure .8.
PART NUMBER DESCRIPTION # REQUIRED
100550-Z Screw, M3 X 5 12
102464-Z Washer 12
401277 (W1) Main wire harness 1
102030 Power supply, +5V, +-15V 1
102236 Power supply, 12V 1
122514 Mounting bracket 2
5.1.5.1.6 Front Panel Assembly
See Section 5.1.5.2 Figure .9.
PART NUMBER DESCRIPTION # REQUIRED
100970-Z Hex nut, M3 2
100984-Z Phillips screw, M3 X 6 2
102464-Z Lock washer 4
100171 Female stud, M3 X 10 2
100528 Female stud, M3 X 6 4
100739 Washer 4
102066 Alpha-Numeric display 1
122517 Front panel overlay 1
122555 Front panel 1
401093 Key pad interface board 1
