MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
69
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Frame Assembly
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 PG-10306 MAIN FRAME ASSEMBLY 1
2 PG-10305 POWERBOX FRAME ASSEMBLY 1
3 BG005341 STEER 1
4 PA-10868 HANDLE BUSHING 1
5 BG11757 PIN 1
6 BG11750 PIN, KNURLED HANDLE 1
7 PG-10334 WATER TANK, IMPERIAL 1
8 CP-10263 HAIRPIN COTTER PIN 1
9 800838 M12 X 1.75 X 40MM HEX HEAD CAP SCREW 6
10 4501710 WHEEL 2
11 PA-10876 WHEEL SUPPORT, MAIN FRAME 2
12 800798 WASHER, 12MM, NARROW 10
13 CP-10036 15MM RETAINING RING, EXTERNAL 2
14 PA-10852 BRACKET / STEER 1
15 800842 M12 X 1.75 HEX NUT 4
16 BG11860 WATER TAP 1
17 800779 M6 X 1.0 X 16MM SOCKET HEAD CAP SCREW 6
18 800774 FLAT WASHER, 6MM, NARROW 6
To Next Page
