MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
71
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Upper & Lower Assemblies Combined
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 PG-10297 UPPER ASSEMBLY 1
2 PG-10299 LOWER ASSEMBLY 1
3 PA-10249 MACHINED COUPLING 1
4 BG005311 MOTOR SEAT 1
5 BG005310 FLANGE, MOTOR SEAT 1
6 PA-10858 MOTOR COUPLING 1
7 CP-10052 SPIDER 1
8 BG11960 MOTOR 1
9 BG005347 PROTECTION CAP 1
10 BG11924 UPPER DRIVE BELT 1
11 BG005539 COVER HOUSING 1
12 BG11925 DUST RING 1
13 PG-10309 WATER PIPE ASSEMBLY (OPTIONAL) 1
14 BG11797 SEAL 1
15 BG11780 KEY 1
16 800774 FLAT WASHER, 6MM, NARROW 4
17 800775 FLAT WASHER, 8MM, NARROW 2
18 800779 M6 X 1.0 X 16MM SOCKET HEAD CAP SCREW 4
19 800830 M14 X 2.0 X 110MM SOCKET HEAD CAP SCREW 4
20 05-91578 M8 X 1.25 X 16MM HEX HEAD CAP SCREW, 2
21 5001090 FLAT WASHER, 14MM 4
22 5036870 M14 X 2.0 X 40MM HEX HEAD CAP SCREW 4
23 800857 M8 X 1.25 X 90MM SOCKET HEAD CAP SCREW 6
