MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
89
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Diamond Plate Holder
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 BG11809 TOOL HOLDER 1
2 BG11811 CENTERING STAR 3
3 800811 M6 X 1.0 X 12MM FLAT HEAD SOCKET CAP SCREW 6
4 BG11808 MAGNET HOLDER 3
5 BG11807 MAGNET 3
6 BG11806 BUFFER SOFT 3
7 BG11805 BUFFER PLATE 1
8 800827 WASHER, FLAT, M8, WIDE 1
9 800828 M8 X 1.25 X 25MM HEX HEAD BOLT 1
10 800781 M8 X 1.25 X 15MM SOCKET HEAD CAP SCREW 3
