Diamatic BMG-535 - 4 Bearing

MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
79
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Lower Belt Tensioner
ITEM NO. PART NUMBER DESCRIPTION QTY
1 BG005332 HOLDER, LOWER BELT TENSIONER 1
2 BG005333 TENSIONER, LOWER 1
3 BG005337 AXLE, LOWER TENSIONER 1
4 BG11792 BEARING 4
5 BG005336 PULLEY 1
6 BG11793 RETAINING RING, 35MM, INTERNAL 2
7 BG11794 RETAINING RING, 15MM, EXTERNAL 2
8 800785 M8 X 1.25 X 30MM FLAT HEAD SOCKET CAP SCREW 2
9 800790 M10 X 1.5 X 30MM SOCKET HEAD CAP SCREW 1
10 800791 FLAT WASHER, M10 1
11 800826 M8 X 1.25 X 50MM HEX HEAD CAP SCREW 1
12 5028810 M8 X 1.25 HEX NUT 1
