MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
77
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Upper Belt Tensioner
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 BG005831 TENSION PLATE 1
2 BG005830 AXLE 1
3 BG11911 BEARING 2
4 CP-10040 RETAINING RING, 20MM, EXT 1
5 800790 M10X1.5X30MM SOCKET HEAD CAP SCREW 1
6 800791 FLAT WASHER, M10, NARROW 1
7 800792 M10 X 1.5 X 30MM FLAT HEAD SOCKET CAP SCREW 1
8 4774800 LOCK WASHER, M10 1
