MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
81
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Tooling Pulley Assembly
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 PA-10921 AXLE, TOOLING DRIVE, IMPERIAL 1
2 BG11817 BEARING 2
3 BG005317 BEARING HOUSE 2
4 BG11801 RETAINING RING, 30MM, EXTERNAL 4
5 BG11814 RETAINING RING, 62MM, INTERNAL 4
6 BG11780 KEY 1
7 PA-10924 PULLEY, IMPERIAL 1
8 BG11819 TAPER LOCK BUSHING 1
9 CP-10054 DOWEL PIN 3
