MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
75
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Lower Assembly
ITEM NO.
PART
NUMBE
R
DESCRIPTION QTY
1 BG005314
A
DAPTER RING 1
2 BG005322 HOUSING 1
3 BG005324 LOWER PLATE 1
4 BG005326 RING 3
5 BG005327 COVER 4
6 BG005350 INSPECTION COVER 2
7 BG11829 V-RING SEAL 3
8 BG11849 V-RING SEAL 1
9 BG11928 LOWER BELT 1
10 PA-10845 UPPER PLATE 1
11 PG-10290 TOOLING DRIVE AXLE ASSEMBLY 3
12 PG-10291 LOWER TENSIONER ASSEMBLY 1
13 PG-10292 DRIVING PULLEY ASSEMBLY 1
14 PG-10293 DIAMOND HOLDE
R
3
15 800840 M6 X 1.0 X 50MM FLAT HEAD SOCKET CAP SCREW 2
16 5028750 M6 X 1.0 X 15MM HEX HEAD CAP SCREW 36
17 5037600 LOCK WASHER, M6 78
18 05-91578 M8 X 1.25 X 16MM HEX HEAD CAP SCREW 6
19 800848 LOCK WASHER, M8 10
20 800839 M6 X 1.0 X 25MM HEX HEAD CAP SCREW 42
21 800803 M8 X 1.25 X 20MM HEX HEAD CAP SCREW 4
