MODEL BMG-535 GRINDER
SECTION 10 SPARE PARTS
73
OPERATING MANUAL
APRIL 2009
Grinding & Polishing
Upper Assembly
ITEM NO.
PART
NUMBE
R
DESCRIPTION QTY
1 BG005309 MOTOR PLATE ASSEMBLY 1
2 BG005313 HOLDER 2
3 BG007834 LOWER PLATE UPPER DRIVE 1
4 PG-10044 TENSIONER UPPER BELT 1
5 PG-10300 CENTER PULLEY ASSEMBLY 1
6 PG-10301 CONTRA PULLEY ASSEMBLY 1
7 PA-10250 PROTECTION CAP SUPPORT 2
8 BG11904 MIDDLE BELT 1
9 800787 M8 X 1.25 X 30MM SOCKET HEAD CAP SCREW 6
10 800775 FLAT WASHER, 8MM, NARROW 6
11 800789 M14 X 2.0 X 30MM HEX HEAD CAP SCREW 1
12 5001090 FLAT WASHER, 14MM 1
13 800788 M8 X 1.25 X 45MM HEX HEAD CAP SCREW 1
14 5028810 M8 X 1.25 HEX NUT 1
15 5028750 M6 X 1.0 X 15MM HEX HEAD CAP SCREW 1
