Fig. 1. Data plate ie.
ed. 0116 rev. 00 5
THECNICAL DATA
1.3 DATA PLATE
The marking or data plate is located on back of the unit
and the small data identification on front control panel.
The meaning of the various information is listed below:
1.3.1 LEGGEND OF DATA PLATE.
F.Mod.
Factory model description
Comm.Model
Commercial description
PNC
Production number code
Ser.No
Serial number
El
Power supply voltage / phase
Hz
Power supply frequency
kW
Max. power input
A
Current absorption
Power unit El.
Power
I
Dust and water protection rating
CE
CE marking
L
Logo IMQ/GS
Manufacturer:
Electrolux Professional SPA
Viale Treviso, 15
33170 Pordenone (Italy)
1.3.2 TECHINAL DATA
A. TABLE -
B. REFER TO SINGLE UNIT FOR MORE DET-
TAILS PRESENT ON DATA PLATE
Max load
KG 30 50 70 100 180
Power supply
V 400
Phase
n° 3N
Frequency
Hz
50/60
IMPORTANT!
IMMEDIATELY CHECK FOR ANY DAMAGE
CAUSED DURING TRANSPORT.
