Diamond SmartLyte Plus - Interface PC

1 Introduction
ECO 9099 SOP05-5090F Rev.00 Effective Date: 12/20/18 Page 39 of 58
Figure 1-57 Valve Board, Rear
1.3.1.15. Interface PC
This unit is located on the Rear Panel.(See figure 4.42)
Figure 1-58 Interface- PC
Display Cable
Connector
Data Module
Connector
Interface PC
Module
SD Card
