1.3. Description of Modules
1.3.1. Mechanical Assemblies
1.3.1.1. Front Door Assembly
The front door assembly is comprised of the following parts,
1. Front Door
2. Plastic Window
3. EMI Window
4. Door Magnets
Figure 1-3 Front Door Assembly, Front View
Front Door
Assembly
Plastic Window
on Front
