19
500Ub.Sr Service Menus
There are two service menus on this console:
The Console Diagnostics menu which checks the functionality of the console. It also displays the A.
software version and the accumulated run time. In addition it has a Model Switching feature that
changes the active model the console is operating on from 2 options: Cycles and ellipticals
The English and Metric switching menu which changes the display units from pounds, miles, and B.
miles/hour to kg, km and km/hour.
Console DiagnosticsA.
Press and hold the Enter Key for 2 seconds1.
Press Enter Key to toggle through the Service Mode states. To terminate the Service mode without 2.
going through all the steps, press & hold “Stop” key for 2 seconds to reset the console.
Software Version – The Dot Matrix display will display the software as “SW” “1.0”3.
First display “SW”a.
Then display “1.0” and it will Wait for the Enter key to be pressedd.
Reset to Factory Defaults – When the Enter key is pressed after the software version is displayed, it 4.
will allow for the console to be reset to Manufacture defaults.
The Dot Matrix will fl ash “RS”, and then display an “N”. The Up and Down keys can be use to a.
toggle between an “N” and a “Y”.
If the Enter key is pressed while the “N” is on the display nothing will change.b.
If the Enter key is pressed while the “Y” is on the display the model setting will change to UR, Age c.
will rest to 35years, the Weight will reset to 155lbs, the Custom Trainer profi le will reset to its de-
fault profi le (see section 11.3.4 for profi le)
Model Setting: When the Enter key is pressed after the Reset to Facture selection is done the Dot 5.
Matrix will display confi guration of the console as “UR” or “EF”.
Up/Down keys can be pressed at this point to switch the mode. The mode determines which a.
Watt table and Calorie calculation is used.
Wait for the Enter key to be pressed to move to the next step in Service Mode.b.
Memory Test – When the Enter key is pressed after the Model Setting is done, it will test the memory, 6.
if OK it will display “OK” in Dot Matrix or “NG” if it is bad.
Accumulated time – When the Enter key is pressed after the memory test is completed, it will display 7.
the accumulated time in the time display.
Perform Display test – When the Enter key is pressed after the accumulated time is displayed, enter 8.
the display test.
All of the LEDs, and in the LCD will light up at once.a.
All LEDs and displays will turn offb.
