Diamondback 500Ub - 500 Sr Parts List

72
500Sr Parts List
30
32
35
36
38
51
53
54
57
58
76
77
78
65
66
79
69
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
Exploded
Drawing
Number DB Part Number Description Page No.
101 22-50-101 Console Assembly
105 22-50-105 HP Sensors
111 22-50-111 Water Bottle Set
113 22-50-113 Console Mount Covers
117 22-50-117 Console Mount
143 22-50-143 Crank Insert
147 22-50-147 Leveling Caps
149 22-50-149 Transport Wheels
157 22-50-157 Left Crank Arm
159 22-50-159 Right Crank Arm
161 22-90-161 Crank Arm Hex Nut
168 22-50-168 Drive Pulley
169 22-90-169 Drive Belt
173 22-50-173 Idler Assembly
175 22-50-175 Speed Sensor
177 22-50-177 Input Jack
181 22-50-181 Console Back Panel
203 22-50-203 Console Mast
209 22-90-209 Handle Bar Endcaps
211 22-50-211 Foam Grips
215 22-50-215 Console Mast Cover
217 22-50-217 HP Wire Harness - Console Mast
219 22-50-219 Main Wire Harness - Console Mast
221 22-50-221 HP Wire Harness - Frame
223 22-50-223 Main Wire Harness - Frame
225 22-50-225 HP Wire Harness - Frame Rear
227 22-50-227 HP Wire Harness - Rear Handle Bar
233 22-50-233 Left Sidecase
235 22-50-235 Right Sidecase
239 22-50-239 Sidecase Bolt Kit
241 22-50-241 Rear Left Lower Sidecase
243 22-50-243 Rear Left Upper Sidecase
245 22-50-245 Rear Right Lower Sidecase
247 22-50-247 Rear Right Upper Sidecase
255 22-50-255 Rear Handle Bar
257 22-50-257 Seat Back Support
259 22-50-259 Seat Back Mount Bracket
261 22-50-261 Seat Back Adjusment Knob
263 22-50-263 Seat Back Pad
265 22-50-265 Seat Pad
267 22-50-267 Seat Mount Bracket
