500Sr Parts List (Constinued)
Exploded
Drawing
Number DB Part Number Description Page No.
269 22-50-269 Seat Slide Frame
271 22-50-271 Seat Slide Adjustment Knob
273 22-50-273 Seat Tube
281 22-50-281 Pedals & Straps
283 22-50-283 Brake Assembly
285 22-50-285 Flywheel
289 22-50-289 Front Stabilizer
291 22-50-291 Rear Stabilizer
293 22-50-293 BB Bearing Set
295 22-50-295 Seat Slide Bushing Set
297 22-50-297 Seat Mount Bracket Bushing
354 22-09-354 AC Adapter
185 22-50-185 Assembly Hardware Kit
900 22-50-900 Owner's manual
