Motor control unit DCM31
12 / 35
d) 2 x 7-Segment: Display menus and states
Gate status (horizontal bar)
[X7]
Segment Segment status Motor Gate status
A Lit 1 Standing in CLOSE end position
B Lit 1 Standing between end positions
C Lit 1 Standing in OPEN end position
D Lit 2 Standing in CLOSE end position
E Lit 2 Standing between end positions
F Lit 2 Standing in OPEN end position
Left Bars moving upwards 1 Opening
Left Bars moving downwards 1 Closing
Left Bar stopped + flashing 1 Last travel was ended with SE, LS
or forced stopping (obstruction!)
Right Bars moving upwards 2 Opening
Right Bars moving downwards 2 Shutting
Right Bar stopped + flashing 2 Last travel was ended with SE, LS
or forced stopping (obstruction!)
Left point
(0)
Lit 1 + 2 Automatic closing is active, keep
open time running
Right
points (0)
Flashing 1 + 2 Automatic closing is active, early
warning running
Input status (vertical bar)
[X7]
Segment Segment status Input
1 lit limit switch M1 OPEN actuated = open
2 lit limit switch M1 CLOSE actuated = open
3 lit input LS pressed = open
4 lit input SE pressed = open or short-circuited
5 lit input A actuated = closed
6 lit input B actuated = closed
7 lit limit switch M2 OPEN actuated = open
8 lit limit switch M2 CLOSE actuated = open
9 lit emergency stop actuated = open
0 lit Automatic closing is active, keep open time running
0 flashing Automatic closing is active, early warning running
Learning runs:
Brief display of the digits 1..4 = number of learning runs still to be performed
separately for M1 (left display) and M2 (right display).
Radio:
- During teaching for radio module mode the display switches between gate status
and {F0}..{F9} for the selected radio function. In addition, the “radio” LED next to
the 7-segment display flashes.
- Deletion of all codes in radio module mode is indicated by rapid flashing of {FL} in
the display and by rapid flashing of the “radio” LED.
- If a teaching radio is detected, the teaching function {F0}..{F9} is shown in the
display and the “radio” LED is lit.
Error messages:
Display switches between “ER” (error) and error number.
