Motor control unit DCM31
16 / 35
7) Menu Table
Grey background: basic values (factory setting)
Basic values
Menu
Value
range
Function / values
[M
.
A0]
=
00
2-leaf.-Hinged
gate
[M
.
A0]
=
01
1-leaf.-Hinged
gate
[M.A0] = 02
Sliding gate
[M.A0] = 03
Folding gate
[M
.
A0]
=
04
Roller
shutter gate
[M.A0] = 05
Type 5
[M.A0] = 06
Type 6
[M.A0] = 07
Type 7
Setting
A0
00
01
02
03
04
05
06
07
DEFAULT SETTING for gate type
2-leaf hinged gate
1-leaf hinged gate
Sliding gate
Folding gate
Roller shutter gate
Type 5
Type 6
Type 7
(Important: Changing effects all other menu items)
Switch over only possible by simultaneously pressing the radio key
00 00 00 00 00 00 00 00
A1 00..20 Motor voltage Smooth travel-out M1 10 10 10 5 10 10 10 10
A2 00..20 Motor voltage Smooth travel-out M2 10 10 10 5 10 10 10 10
A3 00..20 Motor voltage along path M1 20 20 20 20 20 20 20 20
A4 00..20 Motor voltage along path M2 20 20 20 20 20 20 20 20
A5
00
01..20
Length smooth travel motor1 and motor2
No smooth travel-out
Travel time in 0.5 sec steps before end position, start point self-teaching 05 05 05 05 05 05 05 05
A6
00..05
START-UP TIME after motor start (start time, electric lock, electricity
fade-out)
Start up time in 0.5 sec steps, 0.5..3.0 sec
02 02 02 02 02 02 02 02
A7 00..30 Force in open M1 (electricity stop) 15 15 15 15 15 15 15 15
A8 00..30 Force in close M1 (electricity stop) 15 15 15 15 15 15 15 15
A9 00..30 Force in Open M2 (electricity stop) 15 15 15 15 15 15 15 15
b0 00..30 Force in close M2 (electricity stop) 15 15 15 15 15 15 15 15
b1
00
01..62
63..90
AUTOMATIC CLOSING
switched off
keep open time in 2sec steps, plus 5sec early warning
keep open time 63=3min, 64=4min, ... , 90=30min plus 5 sec early
warning
(Number – 60 = time in minutes)
00 00 00 00 00 00 00 00
b2
00
01
02
03
04
05
06
07
08
09
LIGHT / WARNING LIGHT function
Only while motor running
1min overrun travel after motor operation
2min overrun travel after motor operation
3min overrun travel after motor operation
4sec before motor start open and close and while motor running
4sec before motor start open and close and while motor running -
flashing (1Hz)
4sec before motor start close and while motor running
4sec before motor start close and while motor running - flashing (1Hz)
Status display: gate in OPEN end position
Status display: gate in CLOSE end position
02 02 02
00
02 02 02 02
