Motor control unit DCM31
14 / 35
6) Putting into Service / Programming
a) Using menu function
The buttons [Ta.+], [Ta.-] and [Ta.M] next to the display [X7] can be used to
set/change the individual functions of the control unit as follows:
[Ta.M] > pressed for 1 sec = Switch between display
function (display: horizontal or vertical bar)
and setting (display: letters/digits).
[Ta.M] < pressed for 1 sec in function mode = switch between display
gate status (horizontal bar)
and / input status (vertical bar).
[Ta.M] < pressed for 1 sec in setting mode = switch between displays
Menu item (left display letter A, b, C, d)
and menu value (both displays with digits, 00-99)
- Use [Ta.+] and [Ta.-] to select the menu item to be changed [A0..d9].
- Use [Ta.M] < 1 s to select “Menu value” mode (display 00...99, digits only).
- Use [Ta.+] and [Ta.-] to set the required value.
- Press button < 1 s to reselect “Menu item” mode
- Adjust all settings using this schema.
- If the menu value is changed, this value is automatically adopted and saved.
- If none of the buttons are pressed for longer than 15 sec, the display switches back
to gate status.
- During the setting mode it is not possible for the motor to run.
b) Gate type default setting
After all the additional equipment (SE, LS, ES...) and loads (motor, warning light, ...)
have been connected, the gate type must be set first!
- The gate type can be preset using [M.A0].
- By changing [M.A0], all menu items are preset to the typical values for this type of
gate (factory setting) and the force values and running times are deleted, so that
new teaching runs must be carried out!
- Changing [M.A0] via [Ta.+] and [Ta.-] is only possible by simultaneously actuating
[Ta.F], to prevent accidental adjustment!
c) Programming
Use the table from page 16 to set the required parameters for the individual menu
items, and enter the selected values in the “Setting” column.
d) Deleting the force values and travel paths
- - Press [Ta.-] and [Ta.+] simultaneously until “44” flashes in the display. During the
deletion the two points in the display flash rapidly.
- - Important: New teaching runs must be completed (see below).
e) Teaching runs / learn force values
- If all menu items have been set, 4 complete teaching runs from limit switch to limit
switch must be completed to learn the force values and travel paths (for operation
without limit switch [M.C6] = 02 only 2 teaching runs).
