8) Functional Description
a) Radio module
- The radio frequency and modulation type is determined by the plug-in radio module
in [Bl.1].
- The transmitter coding is teaching. Up to 40 codes (transmit keys) can be teaching
with different functions.
- The motor control unit can either learn the 12 bit dual coding schema, the 18 bit
tristate coding schema or Keeloq coding. Further coding types by arrangement.
- The type of coding schema is specified during teaching of the first transmitter –
after deleting all codes. The first learning process can take up to 10s!
- If an already teaching transmitter is re-teaching, the control unit recognises this and
does not allocate any more of the 40 memory locations.
Teaching a transmitter:
• Briefly press [Ta.F] once. Radio LED flashes.
• The 7 segment display shows which function is being learnt.
• Press [Ta.F] until the required function is displayed (F0..F9).
• Press the transmit key to be teaching until the “Radio” LED is permanently lit.
The transmitter has now been teaching.
• If a transmitter is not teaching, learn mode is automatically quit after 15 s.
Functions for operation with radio module
• {F0} Pulse (open-stop-close-..) (not for dead man)
• {F1} Open pulse with panic function, i.e. stop while motor running
• {F2} Close pulse with panic function, i.e. stop while motor running
• {F3} Stop
• {F4} Partial opening / active leaf *
• {F5} Light
• {F6} Open pulse (without panic function)
• {F7} Close pulse (without panic function)
• {F8} OUT relay (active if [M.C4] = 04) pulse function
• {F9} OUT relay (active if [M.C4] = 04) current surge function
* Note:
If dead man function is set via [M.b9], the relevant direction of travel cannot be
controlled by radio!
Delete all transmitters:
• Keep [Ta.F] pressed for approx 6 s.
• Radio LED flashes fast and in {FL} flashes in the display.
• If the flashing stops, all coding is deleted.
b) Input A and B and radio receiver
- The inputs A and B and channels 1 and 2 of the radio receiver slot are connected
in parallel.
- The function of the inputs A, B [Kl.25]+[Kl.26]+[Kl.27] and the radio receiver in
[Bl.2] can be selected via [M.b9] between open, close, pulse and partial opening.
- If dead man’s mode is set, radio mode via the radio module is blocked for the
relevant direction of travel. Operation with radio receiver in [Bl.2] is not permitted in
this direction of travel.
