Motor control unit DCM31
17 / 35
Basic values
Menu
Value
range
Function / values
[M
.
A0]
=
00
2-leaf.-Hinged
gate
[M
.
A0]
=
01
1-leaf.-Hinged
gate
[M.A0] = 02
Sliding gate
[M.A0] = 03
Folding gate
[M
.
A0]
=
04
Roller
shutter gate
[M.A0] = 05
Type 5
[M.A0] = 06
Type 6
[M.A0] = 07
Type 7
Setting
b3
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
ELECTRICITY STOP / obstruction detection
opening: no effect closing: no effect
opening: no effect closing: stop
opening: no effect closing: release
opening: no effect closing: reversing
opening: stop closing: no effect
opening: stop closing: stop
opening: stop closing: release
opening: stop closing: reversing
opening: release closing: no effect
opening: release closing: stop
opening: release closing: release
opening: release closing: reversing
opening: reversing closing: no effect
opening: reversing closing: stop
opening: reversing closing: release
opening: reversing closing: reversing
Important: If electricity stop “no effect” the control unit can be damaged
or destroyed in the event of overload!
10 10
11
05
07
10 10 10
b4
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
PHOTOELECTRIC BARRIER function
opening: no effect closing: no effect
opening: no effect closing: stop
opening: no effect closing: release
opening: no effect closing: reversing
opening: stop closing: no effect
opening: stop closing: stop
opening: stop closing: release
opening: stop closing: reversing
opening: release closing: no effect
opening: release closing: stop
opening: release closing: release
opening: release closing: reversing
opening: reversing closing: no effect
opening: reversing closing: stop
opening: reversing closing: release
opening: reversing closing: reversing
10 10
03 03
10 10 10 10
b5
00
01..20
Close after leaving the photoelectric barrier
Function switched off
Delay time in 0.5sec steps
00 00 00 00 00 00 00 00
