17.3. Quality of the tools and chucks
Tool shafts and shrink fit chucks must have the following characteristics to guarantee a
easy on- or unshrinking process.
17.3.1. Tool shanks
 must be smooth
 must be free of oil and grease
 preferably should not have a clamping face
 must not have any marking with raised areas
 must have the necessary tolerance quality
The following shank tolerances are required for the various shank diameters:
Shank-Ø
Shank tolerance
Tool type
3 mm
h4
Carbide
4 mm
h4
Carbide
5 mm
h5
Carbide
≥ 6 mm
h6
Carbide or HSS
17.3.2. Shrink fit chuck holes
 must be smooth
 must be free of oil and grease
 must have the necessary quality of tolerance
