15. Symbols and pictograms
Warnings: Are marked by warning triangles with a hazard symbol, and warn of
dangers resulting in personal injury or damage to property.
General warning
Hazard posed by electric current or voltage
Commands: Are marked by circles with hazard symbol or square with instructions,
and describe an activity or the use of certain items or objects.
Wear goggles
Wear safety gloves
Notes: Are marked by the information pictogram and contain recommendations
or other additional information.
Example:
Detailed instructions for the chemical test method are available from
your supplier.
Lists: Are marked by the symbol 
Example:
 Can be used for high speeds
 Highest clamping forces
 Slim body chuck
Activities: Are marked by the symbol  and provide instructions for the stated
activity. The result of the activity can be stated as explanation.
Example:
 Change coil
 Set shrinking time
 Remove tool
