Digi XBee Manual

XBee® Wi-Fi RF Modules
© 2013 Digi International, Inc. 108
Dipole Antennas
Minimum Cable Loss/Power
Reduction/Attenuation Required
Part Number Type (Description) Gain Application
Min
Separation b mode
g mode
n mode
A24-HASM-450
Dipole (Half-wave articulated
RPSMA-4.5")
2.1
dBi Fixed/Mobile 20 cm N/A N/A N/A
A24-HABSM Dipole (Articulated RPSMA)
2.1
dBi Fixed 20 cm N/A N/A N/A
A24-HABUF-P5I
Dipole (Half-wave bulkhead
mount U.FL s/ 5" pigtail)
2.1
dBi Fixed 20 cm N/A N/A N/A
A24-HASM-525
Dipole (Half-wave articulated
RPSMA-5.25")
2.1
dBi Fixed/Mobile 20 cm N/A N/A N/A
Omni-Directional Antennas
Minimum Cable Loss/Power
Reduction/Attenuation Required
Part Number Type (Description) Gain Application
Min
Separation b mode g mode n mode
A24-F2NF
Omni-Directional (Fiberglass
base station)
2.1
dBi Fixed/Mobile 20 cm N/A
N/A N/A
A24-F3NF
Omni-Directional (Fiberglass
base station)
3.0
dBi Fixed/Mobile 20 cm N/A
N/A N/A
A24-F5NF
Omni-Directional (Fiberglass
base station)
5.0
dBi Fixed 20 cm N/A N/A N/A
A24-F8NF
Omni-Directional (Fiberglass
base station)
8.0
dBi Fixed 2 m N/A 0.4 dB 0.4 dB
A24-F9NF
Omni-Directional (Fiberglass
base station)
9.5
dBi Fixed 2 m 0.4 dB 2.4 dB 2.4 dB
A24-F10NF
Omni-Directional (Fiberglass
base station)
10
dBi Fixed 2 m 0.9 dB 2.9 dB 2.9 dB
A24-F12NF
Omni-Directional (Fiberglass
base station)
12
dBi Fixed 2 m 2.9 dB 4.9 dB 4.9 dB
A24-F15NF
Omni-Directional (Fiberglass
base station)
15
dBi Fixed 2 m 5.9 dB 7.9 dB 7.9 dB
A24-W7NF Omni-Directional ( base station)
7.2
dBi Fixed 2 m N/A 0.1 dB 0.1 dB
A24-M7NF
Omni-directional (Mag-mount
base station)
7.2
dBi Fixed 2 m N/A 0.1 dB 0.1 dB
PANEL CLASS ANTENNAS
Minimum Cable Loss/Power
Reduction/Attenuation
Required
Part Number Type (Description) Gain Application Min Separation
b
mode
g mode
n mode
A24-P8SF Flat Panel 8.5 dBi Fixed 2 m N/A
1.4 dB 1.4 dB
A24-P8NF Flat Panel 8.5 dBi Fixed 3 m N/A
1.4 dB 1.4 dB
A24-P13NF Flat Panel 13 dBi Fixed 4 m 3.9 dB
5.9 dB 5.9 dB
A24-P14NF
Flat Panel
14 dBi
Fixed
5 m
4.9 dB
6.9 dB
6.9 dB
A24-P15NF Flat Panel 15 dBi Fixed 2 m 5.9 dB
7.9 dB 7.9 dB
A24-P16NF Flat Panel 16 dBi Fixed 2 m 6.9 dB
8.9 dB 8.9 dB
A24-19NF Flat Panel 19 dBi Fixed 2 m 9.9 dB
11.9 dB
11.9 dB
