XBee® Wi-Fi RF Modules
© 2013 Digi International, Inc. 109
YAGI CLASS ANTENNAS
Minimum Cable Loss/Power
Reduction/Attenuation
Required
Part Number Type (Description) Gain Application
Min
Separation
b
mode
1.7 dB 1.7 dB
A24-Y7NF Yagi (7 element) 9.0 dBi Fixed 2 m N/A
1.9 dB 1.9 dB
A24-Y9NF Yagi (9 element) 10.0 dBi Fixed 2 m 0.9 dB
2.9 dB 2.9 dB
A24-Y12NF Yagi (12 element) 12.0 dBi Fixed 2 m 2.9 dB
4.9 dB 4.9 dB
4.9 dB 4.9 dB
A24-Y15NF Yagi (15 element) 12.5 dBi Fixed 2 m 3.4 dB
5.4 dB 5.4 dB
A24-Y16NF Yagi (16 element) 13.5 dBi Fixed 2 m 4.4 dB
6.4 dB 6.4 dB
Yagi (16 element, RPSMA connector)
A24-Y18NF Yagi (18 element) 15.0 dBi Fixed 2 m 5.9 dB
7.9 dB 7.9 dB
Antennas approved for use with the XBee Wi-Fi Surface Mount Module
Minimum Cable Loss/Power
Reduction/Attenuation Required
Part Number Type (Description) Gain Application
Min
Separation b mode
g mode
n mode
31000005-01 Integral PCB antenna 0 dBi Fixed/Mobile 20 cm N/A
N/A
N/A
A24-QI Monopole (Integrated Whip)
1.5
dBi Fixed/Mobile 20 cm N/A
N/A
N/A
Dipole Antennas
Minimum Cable Loss/Power
Reduction/Attenuation Required
Part Number Type (Description) Gain Application
Min
Separation b mode
g mode
n mode
A24-HASM-450
Dipole (Half-wave articulated
RPSMA-4.5")
2.1
dBi Fixed/Mobile 20 cm N/A
N/A
N/A
A24-HABSM Dipole (Articulated RPSMA)
2.1
dBi Fixed 20 cm N/A
N/A
N/A
A24-HABUF-P5I
Dipole (Half-wave bulkhead
mount U.FL s/ 5" pigtail)
2.1
dBi Fixed 20 cm N/A
N/A
N/A
A24-HASM-525
Dipole (Half-wave articulated
RPSMA-5.25")
2.1
dBi Fixed/Mobile 20 cm N/A
N/A
N/A
