5.1 Operation of dFlow
Figure 01
dFlow, for opening and closing the doors, uses the exclusive motor control that
enables a controlled, soft, quiet and comfortable turn for the user.
The drive unit is driven via direct current but converted through the drive to PWM
signals for subsequent drive of the coil assemblies.
The drive mechanism of the equipment is sealed type and built in robust housing,
with heat dissipation by natural convection, having its mechanical elements,
subject to support efforts, permanently lubricated.
Some motor characteristics:
• Robust
• Reliable
• High performance
• Electronic control
• Silent (Noise: <45dB)
