6.3 Access to dFlow after assembly
Once dFlow is installed and assembled, access to the inside of the equipment can
be done with the key that comes with the equipment by four ways:
• By the two side doors (inside dFlow);
• By the access door to the motor and to the electrical panel on the lower side
and on both sides of dFlow.
Figure 07
Other motors and
communication
connectors
Access cover to the electrical
panel and motor
Circuit breaker
access cover
WARNING
Avoid electric shock! Opening or removing this equipment's cover
may expose you to dangerous voltages.
WARNING
To reduce risk of electric shock, before servicing, turn off the
equipment's electrical power by switching the circuit breaker to the
OFF position. Refer all servicing to qualified service personnel only.
Figure 08
Figure 09
Opening the doors:
Closing the doors:
