22
6.5 Overhead detection system
dFlow has a high level of accuracy and reliability. With it, it is possible to control
the passage direction (the system allows bi-directional operation), and can be
configured to operate different passage directions.
Overhead detection system:
Figure 15
Measures for installation:
Figure 16
INFORMATION:
Ÿ dFlow’s measures are shown in millimeters and (inches).
Ÿ Attach the sensor to the ceiling using a support and a screw so that it
can bear 5kg.
Figura 17
1600
659
940
1100
329
282
(62.99")
(25.94")
(43.30")
(37.007")
(11.10") (12.95")
