• Digicon provides 4 meter long connection cables.
• The depth of the ducts must be dimensioned so that the cables are
sufficient.
After passing the cables through the ducts, the cables must be connected to the
dFlow transmitter terminal block as shown below:
037.12.376
037.12.378
037.12.379
037.12.380
037.12.377
Figure 14
Connect the connection
cables to the dFlow
transmitter terminal block.
Connection cables are
in the dFlow receiver.
Figure 13
dFlow R
dFlow T
dFlow transmitter terminal block:
