6. Installation and assembly
6.1 Opening the package
Since dFlow is configurable equipment, it is extremely important that careful
visual inspection be done before starting the installation and assembly process.
Digicon’s packaging is accompanied by a checklist, which guides this inspection. If
any part is missing, contact a Digicon sales representative immediately.
WARNING
Allow only qualified service personnel to install this equipment. The
installation must conform to all local codes and regulations.
6.2 Fastening on the floor/ground
The figure below indicates the fastening points of the product on the floor/ground.
The surface must be firm and level, to ensure proper operation of the overhead
detection system and to maintain alignment of the doors.
It must be fastened with mechanical anchor bolts, also known as parabolt or
through chemical fastening.
