PASSAGE BOXES
50 mm diameter conduit
Exit
Passage 1
Passageassage 2
6"x6"
Figure 05
INFORMATION: The images above represent a two-passage
installation. For a greater number of passages, assess the amount of
cables and diameter of the ducts.
TIP: Separate the power grid from the logic network.
INFORMATION: The colors of the cables are illustrative.
Preferencial
passage boxes
for AC cable
Preferencial
passage boxes
for AC cable
